Ajax Tools Buyer's Guide: Air Hammer Attachments & Pneumatic Chisels

Why Ajax Tools?

Ajax has been manufacturing professional-grade pneumatic tool attachments for decades. Their air hammer chisels, rivet sets, scrapers, cutters, and specialty attachments are built to withstand the demands of production shops, body shops, and heavy-duty repair facilities. Whether you're splitting rusted ball joints, cutting exhaust pipes, or driving rivets, there's an Ajax tool designed specifically for the job.

This buyer's guide organizes the full Ajax lineup by application so you can quickly find the right attachment for your air hammer.

Understanding Ajax Shank Types

Before ordering, confirm which shank type your air hammer accepts:

• .401 Turn Type Shank: The most common shank for professional air hammers. Most Ajax chisels and attachments are available in this configuration.
• .498 Shank: A larger shank used on heavier-duty air hammers. Look for Ajax tools marked "0.498" for this fitment.
• Non-Turn Type Shank: Some tools like the Ajax 3185 Non-Turn Type Wide Chisel/Scraper use a non-rotating shank design.

Retaining springs and retainers are also shank-specific — see the Accessories section below.

Chisels & Cutting Tools

Flat Chisels

Flat chisels are the workhorse of any air hammer kit, used for cutting, separating panels, and breaking welds. Ajax offers several sizes:

• Ajax 910-2 Wide Flat Chisel, 7" / 2" Blade — wide blade for panel separation and gasket removal
• Ajax 910-11 Flat Chisel, 11" / 3/4" Blade — extended reach for tight spaces
• Ajax 910-18 Flat Chisel, 18" / 3/4" Blade — extra-long reach for deep access
• Ajax 960 Flat Air Hammer Chisel, 5/8" x 7" (.498 shank) — heavy-duty flat chisel for larger hammers
• Ajax 919 Offset Flat Chisel, 30°, 10-1/2" — angled blade for offset access
• Ajax 922 Angle Chisel, 6-3/4" — angled for working in confined areas

Specialty Chisels

• Ajax 940 Moil Point Chisel, 7" — pointed tip for breaking concrete, castings, and heavy rust
• Ajax 925 Pencil Point, 6-1/2" and Ajax 925-18 Pencil Point, 18" — fine point for precision work and pin driving
• Ajax 945 Hammer Chisel, 4-1/4" (.401 shank) and Ajax 967 Hammer Chisel, 4-1/4" (.498 shank) — compact chisels for general hammering
• Ajax 955 Wide Chisel & Scraper — dual-purpose wide blade for scraping and cutting
• Ajax 914 V Chisel / Spot Weld Breaker, 6-1/4" — V-shaped tip for breaking spot welds cleanly

Exhaust & Muffler Cutting Tools

Exhaust work is one of the most common air hammer applications in automotive shops. Ajax makes several dedicated exhaust cutters:

• Ajax 902 Tailpipe Cutter Chisel, 6-7/8" — cuts through tailpipes cleanly
• Ajax 908 Muffler Cutter, 7-1/2" — general muffler cutting
• Ajax 933 Inside Muffler Cutter, 8-1/4" — cuts from inside the muffler body
• Ajax 934 Outside Muffler Cutter, 8-1/4" — cuts from outside the muffler body
• Ajax 932 Kwik Cutter, 8-1/2" — fast cutting for general exhaust work
• Ajax 923 Single Blade Cutter, 5-3/4" — compact single-blade design

Suspension & Steering Separation Tools

Separating ball joints and tie rod ends without damaging boots or threads requires the right chisel geometry. Ajax offers several fork-style separators:

• Ajax 901 Universal Joint & Tie Rod Chisel — universal fit for most ball joints and tie rods
• Ajax 903-1 Ball Joint & Tie Rod Separator Chisel (.401 Turn Type)
• Ajax 968-1 Ball Joint & Tie Rod Separator Chisel (.401 Turn Type)
• Ajax 968 Fork Chisel, 7-1/4" / 1-1/4" Size — larger fork for heavy-duty applications
• Ajax 965 Universal Joint & Tie Rod Chisel (.498 shank) — heavy-duty version for larger hammers

Punches

Ajax piercing punches are used for creating holes in sheet metal, removing pins, and punching through panels:

• Ajax 916 #6 Piercing Punch, 5-1/2"
• Ajax 918 #8 Piercing Punch, 5-1/2"
• Ajax 920 #10 Piercing Punch (.401 Turn Type)
• Ajax 961 Tapered Sheet Metal Punch Chisel, 7"
• Ajax 911 Tapered Sheet Metal Punch Chisel (Shank Type)
• Ajax 963 Straight Punch Chisel, 7" and Ajax 963-18 Straight Punch Chisel, 18"
• Ajax 913-18 Straight Punch Chisel, 18" (.401 Turn Type)

Scrapers

For removing undercoating, gaskets, and adhesives, Ajax scrapers mount directly to your air hammer:

• Ajax 905 Wide Scraper, 6-1/4" — wide blade for large surface scraping
• Ajax 951 Undercoat Scraper, 6-1/2" — designed specifically for undercoating removal

Rivet Tools

Ajax rivet sets are used with air hammers for driving and forming rivets in structural and body applications:

• Ajax 1605 1/4" Round Head Rivet Set
• Ajax 1621 1/4" Brazier Head Rivet Set
• Ajax 1622 5/16" Brazier Head Rivet Set
• Ajax 1636 3/16" Universal Turn Type Rivet Set
• Ajax 1638 5/16" Universal Rivet Set
• Ajax 1603 1-3/4" Turn Type Smoothing Hammer — for finishing and smoothing after riveting

Rivet Cutters

• Ajax 962 Rivet Cutter, 5-3/4"
• Ajax 912 Rivet Cutter Chisel, 5-3/4" (.401 Turn Type)

Bushing & Specialty Tools

• Ajax 1127 Bushing Driver, 9-1/2" (.401 shank) — drives bushings without damage
• Ajax 964 Bushing Splitter Chisel — splits worn bushings for removal
• Ajax 1101 3/8" Nut Splitter, 10" — splits seized nuts without damaging threads
• Ajax 649 Broad Head Bull Pin, 1-1/16" x 10" and Ajax 650 Broad Head Bull Pin, 1-1/4" x 13-3/4" — for aligning structural holes in steel fabrication

Complete Sets

For shops stocking up or technicians building out their kit, Ajax offers pre-configured sets:

• Ajax 9044 4-Piece Body Specialist Chisel Set — curated set for body shop work
• Ajax 9029 Master Chisel Set, 9 Piece — comprehensive set covering the most common air hammer applications

Accessories: Retainers, Springs & Regulators

Keeping your chisels securely seated in the hammer requires the correct retainer or spring for your shank type:

• Ajax 897 Mechanics Aid Retaining Spring (.401 shank)
• Ajax 898 Beehive Retaining Spring (.498 shank)
• Ajax 3300-U Universal Kwik Change Retainer (.401 shank)
• Ajax 3300-9 Kwik Change Retainer
• Ajax 3200-3 Chisel Retainer for Chicago Pneumatic 4447-717
• Ajax 3200-1 Chisel Retainer for Ingersoll-Rand AVC-26
• Ajax 894 1/4" NPT Air Regulator — inline regulator for controlling hammer pressure

Finding This Guide

If you searched for Ajax air hammer chisels, Ajax pneumatic tool attachments, or Ajax chisel set for air hammer — you're in the right place. The full Ajax lineup is stocked and shipped by Tillman Tools.

Have a specific application in mind and not sure which Ajax tool fits? Contact our team and we'll help you find the right attachment.
